Hikvision ColorVu Bullet Camera DS-2CE12DF3T-PIRXOS

Description

2 MP ColorVu PIR Siren Audio Fixed Bullet Camera

• High quality imaging with 2 MP, 1920 × 1080 resolution
• 24/7 color imaging with F1.0 aperture
• Clear imaging against strong back light due to 130 dB true WDR technology
• 3D DNR technology delivers clean and sharp images
• 8 mm, 3.6 mm, 6 mm fixed focal lens
• Up to 40 m white light distance for bright night imaging
• Detects human body through heat-sensitive passive infrared (PIR)
• Active strobe light and audio alarm to warn intruders off
• High quality audio with audio over coaxial cable, built-in mic, and built-in speaker
• Water and dust resistant (IP67)

Name	Bullet Camera
Brand Name	Hikvision ColorVu
Model	DS-2CE12DF3T-PIRXOS(2.8mm) DS-2CE12DF3T-PIRXOS(3.6mm)



Camera

Image Sensor	2 MP CMOS
Max. Resolution	1920 (H) × 1080 (V)
Min. Illumination	0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time	PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Day & Night	24/7 Color Imaging
Angle Adjustment	Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
Signal System	PAL/NTSC
Slow Shutter	Max. 16 times



Lens

Lens Type	2.8 mm, 3.6 mm, 6 mm fixed focal lens
Focal Length & FOV	2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116° 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91° 6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59°
Lens Mount	M12



Illuminator

Supplement Light Type	White Light
Supplement Light Range	Up to 40 m
Smart Supplement Light	Yes




Image Parameters Switch	STD/HIGH-SAT/HIGHLIGHT
Image Settings	Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Smart Light, Anti-Banding, AGC
Frame Rate	TVI: 1080p @ 25 fps/30 fps
Day/Night Mode	Colour
Wide Dynamic Range (WDR)	≥130 dB
Image Enhancement	WDR, BLC, HLC, Global, HLS
White Balance	Auto/Manual
Noise Reduction	3D DNR/2D DNR



Supplement Detection(PIR)

PIR Range	11 m
PIR Angle	Angle : 110°



Interface

Video Output	1 HD analog output
Alarm	1 line out Flashing Light Alarm (Red & Blue)
Audio	Built-in mic



Event

Motion Detection

4 programmable motion areas



General

Material	Front cover: Metal, Main body: Plastic
Dimensions	82.6 mm × 77.1 mm × 213.2 mm (3.25″ × 3.04″ × 8.39″)
Weight	Approx. 467 g (1.03 lb.)
Operating Conditions	-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Communication	HIKVISION-C
Language	English
Power	12 VDC ± 25%, max. 11.4 W *You are recommended to use one power adapter to supply the power for one camera.



Approval

Protection

IP67
