Hikvision EDVR DS-E04HGHI-D

Hikvision EDVR DS-E04HGHI-D

LKR 30,720.00



Name eDVR – 4 Channel
Brand Name Hikvision
Model  DS-E04HGHI-D





1 in stock

SKU: DS-E04HGHI-D Categories: ,

Description

4-ch 1080pLite 1U H.265 eSSD DVR

  • Powered by eSSD technology
  • Deep learning based human and vehicle targets classification of Motion Detection 2.0
  • Scene-adaptive bitrate control video compression
  • Up to 1080p Lite@30 fps encoding capability
  • Low power consumption
  • Audio via coaxial cable



Name eDVR – 4 Channel
Brand Name Hikvision
Model DS-E04HGHI-D



Motion Detection 2.0

Human/Vehicle Analysis







 Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search by object or event type is supported;
Video And Audio
IP Video Input





 1-ch

Up to 1080p resolution

Support H.265+/H.265 IP cameras
Analog Video Input 4-ch

BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI Input 1080p25, 1080p30, 720p25, 720p30
AHD Input 1080p25, 1080p30, 720p25, 720p30
HDCVI Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input Support
HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode HDMI/VGA simultaneous output
Audio Input 4-ch via coaxial cable
Audio Output 1-ch via HDMI
Synchronous Playback 4-ch



Recording

Video Compression H.265 Pro/H.265
Encoding Resolution 1080p Lite/720p/720p Lite/WD1/4CIF/CIF/QVGA
Frame Rate











 Main stream:

1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N)

Note:

1080p Lite/720p is 15 fps by default

Sub-stream:

4CIF@15 fps; CIF/QVGA@25 fps (P)/30 fps (N)
Video Bitrate





 According to the actual scene, scene-adaptive bitrate control technology would automatically allocate appropriate bitrate to ensure the stability of recording period.
Stream Type







 Video, Video & Audio

Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.
Audio Compression G.711u
Audio Bitrate 64 Kbps



Network

Total Bandwidth 64 Mbps
Remote Connection 32
Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS
Network Interface 1, RJ45 10/100 Mbps self-adaptive Ethernet interface



Auxiliary Interface

Capacity







 Built-in 512 GB eSSD (480 GB available)

Note:

The device can store about 4 weeks videos for 4-ch analog cameras (default parameters), this estimation is for reference only.
USB Interface Rear panel: 2 × USB 2.0
Alarm In/Out N/A



General

Power Supply 12 VDC, 1 A
Consumption ≤ 5.4 W (with eSSD)
Working Temperature -10 °C to 45 °C (14 °F to +113 °F)
Working Humidity 10% to 90%
Dimension (W × D × H) 151 × 121 × 46 mm (5.94 × 4.76 × 1.81 inch)
Weight ≤ 0.5 kg (with eSSD, 1.1 lb.)
